BB4178

Box Blades

  • Adjustable scarifier height
  • Hinged tailgate for superior results
  • Hydraulically adjustable scarifier beam
  • Strong frame for toughest jobs
Starting At:


View Product Brochure



Features



Simply remove retainer clips to adjust the heightSimply remove retainer clips to adjust the height
#

The scarifier height is easily adjustable on the BB32, BB33, BB41, and BB42 Series Box Blades. Simply remove the retainer clips to raise or lower the scarifier. Use the low notch for deeper ground penetration.

BB Series Box Blade cutting edge is reversibleBB Series Box Blade cutting edge is reversible
#

The BB Series Box Blade cutting edge ensures precise leveling and a fine finish. It is also reversible for twice the wear life.

Hinged tailgate improves leveling and finishingHinged tailgate improves leveling and finishing
#

The hinged tailgate allows clean-material flow for improved leveling and finishing. Plus, it is built for superior performance when backfilling.

Standard on BB41 and BB42 Series Box Blades Standard on BB41 and BB42 Series Box Blades
#

Knock out big jobs faster with the hydraulically controlled scarifier beam on the BB41 and BB42 Series Box Blades. Raise the scarifiers up for backfilling, then lower them for scraping and leveling, all without leaving the tractor seat.



These box blades come standard with a 50.8-mm x 101.6-mm (2-in. x 4-in.) hydraulic cylinder, pin kit, and hydraulic hose kit.

101.6-mm x 101.6-mm (4-in. x 4-in.) tubular-steel scarifier beam101.6-mm x 101.6-mm (4-in. x 4-in.) tubular-steel scarifier beam
#

The BB32 and BB41 Series Box Blades have a balanced, heavy-duty welded mast and a 101.6-mm x 101.6-mm (4-in. x 4-in.) tubular-steel scarifier beam, delivering added strength for the most challenging jobs. There is no need for gussets.

Specifications
